There are a great number of reasons why you should track with Mo-Sys technology. StarTracker is an absolute system that always knows where it is that is suitable for both AR and VR. With no technician required, StarTracker could be the perfect optical tracking technology for your next project.
Compatible with
StarTracker does not drift, unlike mechanical encoded pedestals that work on dead-reckoning and accumulate error with distance travelled. This excludes them from almost all AR applications. Because StarTracker is always referencing itself to its star map, its position is absolute and drift-free.
StarTracker is the most cost-effective choice for unrestricted, real-time camera tracking. In fact, it is often the only viable option to track cameras in large areas. Having just one tracking sensor camera and lots of inexpensive “stars”, instead of having an array of expensive tracking cameras, makes it cost-efficient. By adding more stars to the ceiling, the tracking volume can be easily extended at a very low extra cost. You can even employ a single StarTracker system in several studios.
The initial set-up and calibration is quick and simple. Once you have applied the "stars" to the ceiling, a major part of the installation is done. From there, you must carry out a brief mapping and calibration process. Multiple cameras in the studio can track off the star map. Once calibrated, the system is fully automatic and starts tracking after being powered on. No extra technician is required for day-to-day operation.
The system looks at “stars”; which are small, identical retro-reflective stickers. These stickers are randomly applied to the studio ceiling or the lighting grid, with no additional structure required. Varying in height, the stars do not have to conform to any pattern and are hardly visible to the naked eye. A small LED sensor, mounted on the studio camera, shines light on the stars. This defines the star map, which allows the StarTracker to report the position and orientation of the studio camera in real time to the rendering engine.
StarTracker offers unlimited freedom of movement and gives accurate position, rotation and lens data in real-time - this makes it ideal for Steadicam and handheld. You can rotate the studio camera 360 degrees, and move it to any position in the studio, even right to the edge, as long as enough “stars” are in sight of the tracking camera. Whereas other systems are often restricted in their tracking volume, StarTracker can track in studios between 3m to 20m in height. Since the camera tracking sensor points up rather than looking into the scene, the tracking is unaffected by studio conditions, such as moving objects, set changes, lighting configurations, reflections and plain green screen environments.
As the “stars” can be applied randomly above the lighting grid, they do not restrict the studio lights in any way. Despite using optical tracking, StarTracker is unique in that it is unaffected by studio lighting. This gives you complete freedom to install and adjust lights as needed.
StarTracker needs minimal maintenance and does not require a tracking operator. In the event of a problem, we can offer fast training and support, be it remote or on-site.
| Weight | 2kg |
| Processor Unit Dimensions | 19 x 14 x 4.5cm |
| Sensor camera unit dimensions | 7.5 x 7.5 x 7.5cm |
| Sensor | IR or Blue LED |
| Power Input | 100V - 240V |
| Data Output | IP or RS422 |
We're just not worried about Mo-Sys. We've done 80+ productions and never had an issue with it.
The StarTracker performed brilliantly. It really is a wonder product.
We've been using the StarTracker for almost two years now and its an incredibly stable system.
StarTracker is extremely robust, once its set up and calibrated, which doesn't take long, you come in in the morning, turn it on and it just knows where it is, and its bullet proof, and that's exactly what you want. It's one less thing we need to worry about.
We've been using Mo-Sys, and Startracker specifically for 3 years. Once you set it up, turn it on and within a couple of seconds it locks in and we're ready to do our virtual productions. Day after day we've been using the same Star Map, and we've been using that same Star Map for probably three years and its just rock solid, every time we turn it on. Every time we do a VR installation, we always recommend Mo-Sys because it is, in our opinion, the most stable, rock solid camera tracking you can get. Mo-Sys has been really great about their support.
Mo-Sys products have allowed me to be a better film maker & work faster, and more efficiently at less cost.
Through the use of StarTracker we are now using real-time navigation using star clusters that get mounted to lighting grids, ceilings or anywhere above. Lighting does not interfere with StarTracker. If a unit gets blocked by lights it still only needs to see 15 stars or so to navigate properly. So a typical arrangement would be 30/40/50 stars at any time but what that enables us to do is, we no-longer need a floor target, so everything is referenced through StarTracker, and therefore every shot is a point-to-point exact measurement from the Mo-Sys StarTracker system.
