The B20 was specially designed to be used on virtual sets, and is particularly suited to long-term installations in TV studios. This robotic camera head is light and affordable, yet still has the same strong gears and fast response as our other heads.
Download Brochure
The B20 can also be used with ShotBox to allow movements to be recorded and then played back with the push of a button. The head comes with a custom TV console giving smooth control with a selection of joysticks. It can also be controlled by the standard Mo-Sys input devices as a very compact and lightweight head for location work. The B20 is the standard head for Mo-Sys e-Crane and ViaDolly.
The hollow shafts put an end to slip-rings. Instead, simply feed the cables through the holes to reduce costs and any risk of failure.
With its full virtual interface and built-in encoders, the B20 provides precise tracking data for augmented graphics or virtual backgrounds in green screen surroundings. The broadcast head interfaces seamlessly to other Mo-Sys devices and in conjunction with e-Crane and lens encoding, forming the perfect kit or creating captivating tracking shots with virtual sets.
| Weight | 10 kg (22 lbs) |
| Payload | 20 kg (45 lbs) |
| Pan/Tilt Speed | 120º /sec |
| Pan/Tilt Range | ±720 |
| Max system bus length (operating distance) | 100 m |
| Max operating distance with optional radio | 300 m |
| Max operating distance with optical fibre bridge | 20 km |
| Pan/Tilt Control Options | Handwheels, pan-bar, touchscreen console, button console, TV console |
| Power | 15-32V (24V nom) 3A (nom) 20 Apk |
| Mains | With PSU 110V-200V |
The Button Console features an elegant and simple to use interface, enabling Mo-Sys remote head settings to be adjusted on the fly, such as speed, feathering, smoothing, and soft stops.
The Mo-Sys Gateway is the brain module of the Mo-Sys system. It converts bus data to serial RS422/232 data for VR applications, utilising our own F4 protocol.
PanBar is a fluid head, designed in collaboration with Cartoni. The mechanics and our high precision electronics make the PanBar an alternative solution for pan and tilt control.
Record and recall precise positions using our standard, easy to use Mo-Sys Shotbox
The touchscreen console is a great addition to any of our heads or robotics, allowing the speed of tilt and pan to be adjusted.
The handwheel system is fully adjustable and goes in a travel box as one unit, which makes the set up quick and easy.
